Rivet Threaded Insert Tool Bit Trays
von 2manytoyz
Druckbare Dateien (11)
-
stlRivet_Tool_Bit_Tray_M3_v1.stl
54 Ko · 267 Downloads
-
stlRivet_Tool_Bit_Tray_M4_v1.stl
27 Ko · 275 Downloads
-
stlRivet_Tool_Bit_Tray_M5_v1.stl
43 Ko · 277 Downloads
-
stlRivet_Tool_Bit_Tray_M6_v1.stl
52 Ko · 273 Downloads
-
stlRivet_Tool_Bit_Tray_M8_v1.stl
61 Ko · 269 Downloads
-
stlRivet_Tool_Bit_Tray_M10_v1.stl
50 Ko · 272 Downloads
-
stlRivet_Tool_Bit_Tray_6-32_v1.stl
96 Ko · 279 Downloads
-
stlRivet_Tool_Bit_Tray_8-32_v1.stl
105 Ko · 269 Downloads
-
stlRivet_Tool_Bit_Tray_10-24_v1.stl
67 Ko · 275 Downloads
-
stlRivet_Tool_Bit_Tray_1-4-20_v1.stl
68 Ko · 273 Downloads
-
stlRivet_Tool_Bit_Tray_5-16_v1.stl
71 Ko · 276 Downloads
Beschreibung
I bought a couple of different rivet threaded nut insert tools from Amazon. The smaller one comes with 8 different mandrels (Metric M3, M4, M5, M6; standard SAE 1/4-20, 10-24, 8-32, 6-32).
The larger tool comes with 7 mandrels (Metric M10, M8, M6, M5; SAE 10-24, 1/4-20, 5/16-18)
My design is loosely based on the one here: https://www.thingiverse.com/thing:2930968
I didn't use any of the dimensions or files, so this isn't a remix, but hats off to the original design! That design wouldn't work for me since it was intended for 6 mandrels. Both of my tools have more than that. I also didn't want to have to carry the entire set since each of my projects typically only requires one size. Just grab the tray I need and go.
I will make a tool box that all these will fit in, along with the smaller tool, and the wrench. I'll upload the file probably later this week.
These were designed in Fusion 360. I've uploaded the design files, feel free to modify as you desire.
