Sorting Boxes
by gs242
Printable files (16)
-
stlSorting_Box_1x1.STL
325 Ko · 621 downloads
-
stl
Sorting_Box_1x2.STL
313 Ko · 578 downloads
-
stl
Sorting_Box_1x3.STL
315 Ko · 563 downloads
-
stl
Sorting_Box_1x4.STL
314 Ko · 565 downloads
-
stl
Sorting_Box_2x1.STL
314 Ko · 561 downloads
-
stl
Sorting_Box_2x2.STL
318 Ko · 571 downloads
-
stl
Sorting_Box_2x3.STL
316 Ko · 561 downloads
-
stl
Sorting_Box_2x4.STL
315 Ko · 561 downloads
-
stl
Sorting_Box_3x1.STL
316 Ko · 553 downloads
-
stl
Sorting_Box_3x2.STL
316 Ko · 553 downloads
-
stl
Sorting_Box_3x3.STL
315 Ko · 562 downloads
-
stl
Sorting_Box_3x4.STL
315 Ko · 559 downloads
-
stl
Sorting_Box_4x1.STL
315 Ko · 558 downloads
-
stl
Sorting_Box_4x2.STL
315 Ko · 557 downloads
-
stl
Sorting_Box_4x3.STL
315 Ko · 562 downloads
-
stl
Sorting_Box_4x4.STL
315 Ko · 597 downloads
Description
A full assortment of boxes. Since i'm rebuilding my garage I wanted a good way to store my screws, nuts, bolts and special tools. So i created a grid system with boxes. All of these boxes is equipped with a small "handle" and a recess for 9 mm labels. The recess also protects the label since they don't always stick great to printed surfaces.
The 1X1-box is 52.8 mm X 52.8 mm so they fit will in a 53 mm X 53 mm grid. Each 53 mm X 53 mm space is called a module.
Files are available in all combinations up to 4X4 modules.
The idea is to also make custom trays for some tools and accessories, e.g.: rivets and rivet gun in a 4x2 box with two layers.
Also added pictures of a cabinet with drawers suitable for these boxes. Each drawer holds 100 Modules. Each Column of Drawers holds 1100 Modules. The whole cabinet holds 4400 Modules and will not be filled at once, rather at need when i know what each drawer will hold.
If people want drawings of the cabinet I'll try to find the time.
Would be very appreciated with a small coffee-donation if you like the project.
Feel free to remix to fit your needs.
Added Solidworks Files to ease of remix. If you want any other neutral format like step, binary or so just comment and I'll uploaded it for you. All the Sizes of the boxes are in the configurations in the Solidworks file.
EDIT 2020-04-02: Working on adding all thicknesses to all the boxes. Will soon be uploaded to thingiverse.
