Cnc Case (Plotter-Laser-Dramel)

di mertler48

File stampabili (13)

  • stl

    arduino_tutucu.stl

    35 Ko · 1 802 download

    Scarica
  • stl

    arduinoust_kutu.stl

    7 Ko · 1 788 download

    Scarica
  • stl

    x1.STL

    166 Ko · 1 771 download

    Scarica
  • stl

    destekayaklar.stl

    160 Ko · 1 769 download

    Scarica
  • stl

    destek_kalemlik.stl

    13 Ko · 1 797 download

    Scarica
  • stl

    kol_mil.stl

    84 Ko · 1 763 download

    Scarica
  • stl

    kalemlik_Gövde.stl

    30 Ko · 1 786 download

    Scarica
  • stl

    yeksen2.STL

    116 Ko · 1 772 download

    Scarica
  • stl

    mil.stl

    3 Ko · 1 754 download

    Scarica
  • stl

    kalemlik.stl

    170 Ko · 1 758 download

    Scarica
  • stl

    x2.STL

    271 Ko · 1 754 download

    Scarica
  • stl

    yeksen1.STL

    151 Ko · 1 782 download

    Scarica
  • stl

    kalemlik_kayici.stl

    301 Ko · 1 769 download

    Scarica

Descrizione

hello everyone

https://youtu.be/MexhqOIeTKw

you can use this cnc case to use multi option this plotter version the other version will coming times laser and dramel

need to materials

13x608zz bearing
2xnema17 stepper
GT2 belt 2m
2xGT2 pulley 20 teeth 8mm
2xGT2 20 tooth pulley 5mm
26XM3 stamp
8XM4 stamp
4XM4 nut
4XM4x30mm screw
3xM3x50mm screw
1xcouple 5x8
8XM3x30mm screw
17XM3 nut
4xM3x10mm screw
4XM3x40mm screw
14XM5x30mm chipboard screw
4XM5x30mm screw
M8x560mm gjon shaft
6XM3x10mm screw
20x40sigma 530mm
2pcs 20x40sigma 500mm
2 pcs 20x40sigma 480mm
8 corner connections
16 pieces of impus bolts M4 * 8
16pcsThreaded nut 20-25m4

Tag

#cnc #cnc case #laser #Plotter #router
