PCStand
por JKUgalde
Ficheiros imprimíveis (7)
-
stlConectorB1.stl
38 Ko · 276 descargas
-
stl
ConectorB2.stl
37 Ko · 271 descargas
-
stl
ConectorA.stl
38 Ko · 269 descargas
-
stl
ConectorC2.stl
40 Ko · 286 descargas
-
stl
ConectorC1.stl
40 Ko · 274 descargas
-
stl
FrontSupport.stl
29 Ko · 280 descargas
-
stl
Knob.stl
201 Ko · 280 descargas
Descrição
It is a foldable pc stand, the angle is adjusted using two knobs that press the axis tube to prevent rotation.
To assemble it, you require:
- 2 Front support
- 2 Knobs
- 2 ConectorA
- One of every other piece.
- 9.5 mm aluminium tubes. The length is custom, i used 2 of 200 mm, 2 of 150 mm and one of 110 mm to produce the stand in the photo.
The knobs needs M3 bolts and nuts. Every piece add the possibility to fasten with bolts trough a hole, but it is better to glue everything.
