Prosthesis Leg

par ChristianSilva

Fichiers imprimables (18)

  • stl

    menisco_x1.stl

    2 Mo · 5 802 téléchargements

    Télécharger
  • stl

    planta_pie_x1.stl

    2.5 Mo · 5 777 téléchargements

    Télécharger
  • stl

    empeine_pie_x1.stl

    3 Mo · 5 808 téléchargements

    Télécharger
  • stl

    buje_9_x1.stl

    294 Ko · 5 818 téléchargements

    Télécharger
  • stl

    eje_7_x1.stl

    229 Ko · 5 749 téléchargements

    Télécharger
  • stl

    buje_8_x2.stl

    451 Ko · 5 754 téléchargements

    Télécharger
  • stl

    eje_8_x2.stl

    286 Ko · 5 760 téléchargements

    Télécharger
  • stl

    tuerca_789_x8.stl

    109 Ko · 5 750 téléchargements

    Télécharger
  • stl

    buje_7_x1.stl

    350 Ko · 5 750 téléchargements

    Télécharger
  • stl

    eje_9_x1.stl

    198 Ko · 5 791 téléchargements

    Télécharger
  • stl

    barra_central_x1.stl

    1.3 Mo · 5 751 téléchargements

    Télécharger
  • stl

    barra_lateral_x2.stl

    1.3 Mo · 5 803 téléchargements

    Télécharger
  • stl

    punta_pie_x1.stl

    3.9 Mo · 5 748 téléchargements

    Télécharger
  • stl

    eje_pierna_posterior_derecho_x1.stl

    2.5 Mo · 5 782 téléchargements

    Télécharger
  • stl

    eje_pierna_posterior_izquierdo_x1.stl

    2.5 Mo · 5 759 téléchargements

    Télécharger
  • stl

    eje_central_pierna_x1.stl

    5.1 Mo · 5 791 téléchargements

    Télécharger
  • stl

    rodilla_superior_x1.stl

    3.7 Mo · 5 770 téléchargements

    Télécharger
  • stl

    rodilla_inferior_x1.stl

    8.2 Mo · 5 847 téléchargements

    Télécharger

Description

Prosthesis leg children is based in the research work of the group Osce Days Bogota, Laurent Perrin, Christian Silva and the work of the e_NABLE group ( http://enablingthefuture.org/ ). all this files are covered by creative commons attribution license. Non-Commercial

All reproduction o derivatives from this model should be supervised by a certified professional in the handling of prostheses and orthoses.

It is no a model for comercial use and all kind of intention of sell and make business or take profit from it or any derivation remix etc will be punished by the law

Esta solución protesica solo se podrá adaptar en un paciente niño mayor a 3 años hasta los 10 años bajo la accesoria de una profesional de la salud, terapeuta, fisioterapeuta, fisiatra y con la colaboración de un profesional en psicología

Por favor lea cuidadosamente primero el manual de seguridad y uso de esta solución protesica

Biomechanical design: Christian Silva
Conceptual design and modeling: Osce Days Bogota
Improvement and modular development concept: Laurent Perrin

Prosthesis leg children is a project designed and developed by a group of 3 sections Christian Silva student of Doctorate in the National University of Colombia expert in Biomecanica. Model in turn based on the work directed by the Osce Days Bogota group and improved and modularized by the engineer Laurent Perrin in addition to the e_NABLE group, www.enablingthefuture.org Work developed by the e-Nable Colombia-Give me five team, Fabrilab en Bogotá, with the participation and support of Recreartech in the process of 3D scanning and 3D rendering in 3D printing. All these files are covered by the creative license attribution common goods. Non-commercial, please use the reference from us if you wish to print it.

All parents and children were informed about the study and research for the development of this work. For children ages 3 to 10, the consent was explained by the principal investigator and signed by the children and their parents. The written informed consent of the parents was obtained in order to publish the images and videos that appear in the research study and the research. Detailed safety guidelines were given to parents regarding the use and care of the leg prosthesis.

detailed security guidelines link:
http://enablingthefuture.org/build-a-hand/safety-guidelines/

The pieces are printed on flexible materials such as Filaflex and rifidies such as PET-G

Fabrilab www.fabrilab.com.co

This prosthetic solution can only be adapted in a patient from 3 to 10 years old under supervision to a health professional, therapist, physical therapist, physiatrist and with the help of a professional in psychology

Please read the safety manual and use of this prosthetic solution carefully first

Diseño biomecanico: Christian Silva
Diseño conceptual y modelado: Osce Days Bogota
Concepto de mejora y desarrollo modular: Laurent Perrin

Print Settings

Printer Brand:

Printer: Prusa I3

Rafts: Does not Matter

Supports: Yes

Resolution: 0.15 mm

Infill: 95%

Tags

#enable #Leg #prosthesis
