Inductive sensor 2020 mount

par McPaul1

Fichiers imprimables (1)

  • stl

    ind_mount2020.stl

    417 Ko · 523 téléchargements

Description

It is the mount of 12mm inductive Z-home sensor to the 2020 frame.
13mm from center of the probe to the edge.

2pcs M3x10 DIN 963 (ISO 2009)
2pcs M3 T nuts
LJ12A3-4-Z/BX sensor

This sensor has inverted signal, so in order to work it properly correct the
Marlin 1.1.9 or 2.0
Configuration.h file:

define Z_MIN_ENDSTOP_INVERTING true

Configuration_adv.h

define Z_HOME_BUMP_MM 2

Tested on MKS GEN L and SKR 1.3 boards. No additional hardware needed.
Red (brown) +5v
Blue Gnd
Black S (signal)
