Basic angular velocity sensor
par JustAGermanGuy
Fichiers imprimables (3)
-
stlDisc.stl
253 Ko · 378 téléchargements
-
stl
Bottom_piece.stl
248 Ko · 367 téléchargements
-
stl
Top_piece.stl
164 Ko · 363 téléchargements
Description
you`ll need one 608 bearing, 4x M3 screws and a short piece of M8 threaded rod, a washer(below the disc) and two M8 nuts.
one side houses a standard 5mm Led, the other side houses some kind of LDR.
Obvious dont make it out of clear plastic. that would be stupid
