OKP-7 Red Dot
par Superpoo
Fichiers imprimables (8)
-
stlOKP-7_Red_Dot_-_Body_PT1.stl
149 Ko · 385 téléchargements
-
stlOKP-7_Red_Dot_-_Battery_Screw.stl
18 Ko · 373 téléchargements
-
stlOKP-7_Red_Dot_-_Windage_Screw_X_3.stl
12 Ko · 371 téléchargements
-
stlOKP-7_Red_Dot_-_Reflector_Clamp.stl
14 Ko · 379 téléchargements
-
stlOKP-7_Red_Dot_-_Emitter.stl
82 Ko · 376 téléchargements
-
stlOKP-7_Red_Dot_-_Clamp_X_2.stl
21 Ko · 373 téléchargements
-
stlOKP-7_Red_Dot_-_Shroud.stl
55 Ko · 383 téléchargements
-
stlOKP-7_Red_Dot_-_Body_PT2.stl
223 Ko · 391 téléchargements
Description
Non functional OKP-7 red dot
Full disclosure - I used several files I found on line to get the basic outline, but eventually drafted the entire optic as a new file.
Hardware:
M4 x 30mm countersunk set screw x 2
M4 nut x 2
M3 x 5mm countersunk set screw x 3
5mm Brass Rod - about 22mm long for the on off switch
30mm x 3mm round perspex - can be bought off ebay etc, or cut your own
Optional - I have a bunch or random tiny screws, I used some 1mm set screws for the back of the 'Body Part 1', on the real steel these are a slotted head screw but I only had allen head. In any case you need really small screws...
Finish on the real optic is a textured paint. I sanded the parts then sprayed with bed liner to somewhat simulate the finish.
