U-Joint Demonstration
par lglauberman
Fichiers imprimables (3)
-
stlU_Joint_-_Shaft_2x.stl
88.2 Mo · 328 téléchargements
-
stlU_Joint_-_Base.stl
6.7 Mo · 299 téléchargements
-
stlU_Joint_-_Joint.stl
457 Ko · 297 téléchargements
Description
This is basic U-Joint for demonstration purposes. I drew this up to show how a basic U-joint on a driveshaft works.
It's fairly easy and quick print with no supports required.
Print 2 shafts, 1 joint and 1 base.
Insert the joint into the yokes while rotated at 90°, they will lock into place when the shafts are almost 180° to each other.
The model shown was printed in ABS with a layer height of .16mm.
Please like and upload a make!
