Electron Rocket
por WilliamW
Archivos imprimibles (26)
-
stlStage_1_Engines_Thicker_rev01.STL
1.1 Mo · 2 471 descargas
-
stlPayload_Platform_Black.STL
58 Ko · 4 049 descargas
-
stlStage_1_Bottom_Ring_Grey.STL
23 Ko · 4 047 descargas
-
stlStage_1_Engines_Grey.STL
1.2 Mo · 4 130 descargas
-
stlStage_1_Top_Ring_Grey.STL
23 Ko · 4 032 descargas
-
stlStage_2_Engine_Grey.STL
142 Ko · 4 041 descargas
-
stlStage_2_Small_Cylindrical_Tank_Grey.STL
408 Ko · 4 032 descargas
-
stlStage_2_Top_Ring_Grey.STL
156 Ko · 4 040 descargas
-
stlT.STL
1 Ko · 2 770 descargas
-
stlC.STL
15 Ko · 2 770 descargas
-
stlO.STL
27 Ko · 2 771 descargas
-
stlL.STL
7 Ko · 2 771 descargas
-
stlE.STL
11 Ko · 2 776 descargas
-
stlN.STL
16 Ko · 2 761 descargas
-
stlR.STL
20 Ko · 2 766 descargas
-
stlMounts.STL
37 Ko · 2 786 descargas
-
stlPayload_Fairing_rev1.STL
293 Ko · 2 813 descargas
-
stlStage_1_Battery_Pack_rev1.STL
33 Ko · 2 794 descargas
-
stlStage_2_Tank_rev1.STL
81 Ko · 2 772 descargas
-
stlStage_2_Small_Batteries_Grey.STL
184 Ko · 2 239 descargas
-
stlStage_2_Engine_Nozzle_rev1.STL
420 Ko · 2 084 descargas
-
stlStage_1_Engines_rev1.STL
1.2 Mo · 2 073 descargas
-
stl
Stage_1_Cover.STL
50 Ko · 1 663 descargas
-
stl
Stage_2_Cover.STL
52 Ko · 1 648 descargas
-
stlStage_1_Tank_rev2.STL
37 Ko · 1 473 descargas
-
stlStage_2_Tank_rev1.STL
81 Ko · 1 453 descargas
Descripción
15/04/2020
I combined Stage_2_Engine_Cover_rev1 and Stage_1_Tank_rev1 to make Stage_1_Tank_rev2. Also small change to Stage_2_Tank_rev1 to fit bigger stage 2 nozzle
update
Changed it around a bit to more resemble electron. Added covers, vehicle mounts and lettering.
1/60th Model of Rocket Labs Electron Rocket.
Designed from pictures and wiki for height and diameter.
Electron is a two-stage launch vehicle which uses Rocket Lab's Rutherford liquid engines on both stages. The vehicle is capable of delivering payloads of 150 kg to a 500 km Sun-synchronous orbit.
The Rutherford engine uses pumps that are uniquely powered by battery-powered electric motors rather than a gas generator, expander, or preburner. The engine is also fabricated largely by 3D printing, via electron beam melting
I Designed this to compare the Electron to the Saturn V (https://www.thingiverse.com/thing:911891) Saturn V in picture is not yet complete missing first stage.
Printed in Black and Grey 0.2mm layer for most. 0.1mm on the little Rutherford's
Need some glue to attach nozzle and tiny tanks on the stage 2 engine. Everything else should press fit.
Some sign writing would finish it of pretty good too.
