Combination lock safe
par rndmframes_printing
Fichiers imprimables (17)
-
stlsafe_lever.stl
70 Ko · 1 518 téléchargements
-
stl
safe_shaft.stl
107 Ko · 1 389 téléchargements
-
stl
safe_sled.stl
114 Ko · 1 358 téléchargements
-
stl
safe_shaftHolder.stl
215 Ko · 1 360 téléchargements
-
stl
safe_shaftHolderBrim.stl
211 Ko · 1 339 téléchargements
-
stl
safe_indicator.stl
345 Ko · 1 348 téléchargements
-
stl
safe_sledRod.stl
88 Ko · 1 354 téléchargements
-
stl
safe_spacer.stl
83 Ko · 1 350 téléchargements
-
stl
safe_case.stl
509 Ko · 1 370 téléchargements
-
stl
safe_leverShaftLong.stl
80 Ko · 1 346 téléchargements
-
stl
safe_leverHandle.stl
375 Ko · 1 327 téléchargements
-
stl
safe_leverShaftShort.stl
83 Ko · 1 344 téléchargements
-
stl
safe_pin1and3.stl
92 Ko · 1 344 téléchargements
-
stl
safe_pin2.stl
96 Ko · 1 335 téléchargements
-
stl
safe_disk1.stl
2.3 Mo · 1 353 téléchargements
-
stl
safe_disk2and3.stl
2.5 Mo · 1 348 téléchargements
-
stl
safe_dial.stl
3.1 Mo · 1 348 téléchargements
Description
WITH COMBINATION LOCK
I designed this combination lock in a safe like enclosure.
DOWNLOAD INFORMATION -404-
Please go to Thing Files and download each part separately!
It seems like there is a problem with the download of my recent designs. It has to be a thingiverse problem since other experienced that as well. Hope this gets fixed soon, meanwhile use the little workaround that I mentioned before.
Partlist
- 1x - safe_case
- 1x - safe_sled
- 2x - safe_sledRod
- 1x - safe_shaftHolder
- 1x - safe_shaftHolderBrim
- 1x - safe_shaft
- 3x - safe_spacer
- 2x - safe_disk2and3
- 1x - safe_disk1
- 2x - safe_pin1and3
- 1x - safe_pin2
- 2x - safe_lever
- 2x - safe_leverShaftShort
- 1x - safe_leverShaftLong
- 1x - safe_leverHandle
- 1x - safe_dial
- 1x - safe_indicator
Assembly information
For the assembly it is best to build the lever first. Connect the two levers with their short arms and the "safe_leverShaftShort" to the "safe_sled" than put the second "safe_leverShaftShort" through the long arms of the levers. Put the assembly in the "safe_case" and push the "safe_leverShaftLong" with the "safe_leverHandle" on it through the case and the middle hole of the two levers. Push the two "safe_sledRod" through the sled and the holes of the case, they are the locking bolts of the safe. The "safe_disk1" goes with one "safe_spacer" through the case and gehts connected to the "safe_dial". The three pins are inserted in different positions (this creates the combination). "safe_disk2and3" together with the two spacers are going on the "safe_shaft" wich is going to be mounted to the "safe_shaftHolder" with the "safe_shaftHolderBrim". Last step is to insert the shaft holder with the shaft into the slot an the bottom of the case and glue the "safe_indicator" next to the dial in place.
I also uploaded a pdf with some pictures of the assembly which can be found in the Thing Files.
The tolerances used are tight so drilling and sanding may be required in some places.
